Applications
This machine is perfectly suited for the stranding and cabling processes in the production of:
• Data Communication Cables (Category 5e, Category 6)
• Electronic Hook-up Wires
• Power Supply Cords
• Rubber Insulated Cables
• Control Cables and Flexible Cables
Key Features & Advantages
• High-Speed Operation: Achieves speeds up to 1000 RPM for maximum productivity.
• Double Pitch Design: Offers versatility for different stranding requirements and cable types.
• Wide Application Range: Ideal for data cables (Cat 5/6), electronic wires, power cables, rubber wires, and control cables.
• Precision Tension Control: Electromagnetic automatic tracing ensures consistent and optimal winding tension.
• Robust Construction: Heavy-duty design ensures stability, durability, and long service life under continuous operation.
• Automatic Traversing: Induction-based system guarantees neat and precise wire layering on the take-up spool.
Technical Specifications
Can Be Customized:
| Parameter | Specification |
|---|---|
| Machine Model | High-Speed Double Twister Machine |
| Primary Application | Stranding of multiple insulated core pairs for various cables. Suitable for PE, PVC, and rubber-insulated cores. |
| Core Wire Specification | |
| - Max. Stranding Outer Diameter | 1.5 mm - 3.6 mm (Standard) / Up to 15.0 mm / Up to 4.8 mm (Specific) |
| Stranding Pitch | Adjustable, 25 mm - 200 mm |
| Maximum Machine Speed | Up to 1000 rpm |
| Main Drive Power | 10 HP / 15 HP / 20 HP (Model Dependent) |
| Take-up Spool Size | 500 mm / 630 mm / 800 mm (Model Dependent) |
| Traversing System | Induction-type, Automatic (Electromagnetic Tracing) |
| Braking System | Electromagnetic Brake |
| Take-up Tension Control | Automatic tension tracking via electromagnetic system |
| Overall Machine Weight |
4000 kg / 5000 kg / 6000 kg (Model Dependent) |
OUR SERVICE
Provide Free Pre-sales Training:
We can provide customer training to ensure that the customer can operate the machine fully—this includes correct operating mode, your maintenance method correctly and removing simple problems.
Customer On-site Installation Guide:
The buyer pays for the round-trip airfare, board, lodging, security, and each person's daily wage.
After-sales Service Content Details:
We support the After-sales in response quickly, to complete the delivery.
Free service guarantee period: 12 months from the date of shipment (except for wearing parts).
We will charge you for travel fees and other costs.
If the visa is received on time, our engineers will respond within 24 hours inland and up to 2 weeks overseas.
