SPECIFICATIONS
Can Be Customized:
| Parameter | Specification |
|---|---|
| Spool Diameter Range | Max: φ500 mm, Min: φ300 mm (compatible) |
| Spool Circumference | Full Spool: 1.5 m, Empty Spool: 0.5 m |
| Wire Diameter Range | φ0.3–φ4.5 mm |
| Spool Loading | Manual lifting system |
| Shaft Locking | Hand-tightened taper nuts |
| Braking System | Motor-based dynamic braking |
| Tension Mechanism | Pendulum-type tension arm assembly |
| Tension Adjustment | Sliding counterweight system |
| Tension Control | Potentiometer angle → Voltage signal → Closed-loop motor speed regulation |
| Wire Break Detection | Auto-fault detection with alarm & emergency stop |
| Tension Range | 0–2000 gf (grams-force) |
| Guide Wheels | φ120 mm dual-configuration capstans (3-groove + 2-groove) |
| Drive Power | Configurable AC motor: 0.2–1.5 kW (speed-dependent) |
| Max Spool Weight | 400 kg |
APPLICATION&FEATURES
APPLICATIONS:
Engineered for precision wire/cable processing lines handling Ø0.3–4.5mm diameters. This wire pay-off system excels in fine wire drawing, control cable production, and sensor wire manufacturing. Delivers stable tension for high-quality output in applications demanding exact wire control. Supports spools from Ø300–500mm (400kg max).
FEATURES:
Motorized shaft drive (0.2–1.5kW) with dynamic braking. Pendulum-type tension arm (0–2000gf) adjusted via sliding weights and closed-loop control. Manual spool loading with hand-tightened taper nuts. Integrated wire-break auto-stop safety. Features dual-configuration Ø120mm cast iron guide wheels (3+2 grooves) for durability.
OUR SERVICE
Provide Free Pre-sales Training:
We can provide customer training to ensure that the customer can operate the machine fully—this includes correct operating mode, your maintenance method correctly and removing simple problems.
Customer On-site Installation Guide:
The buyer pays for the round-trip airfare, board, lodging, security, and each person's daily wage.
After-sales Service Content Details:
We support the After-sales in response quickly, to complete the delivery.
Free service guarantee period: 12 months from the date of shipment (except for wearing parts).
We will charge you for travel fees and other costs.
If the visa is received on time, our engineers will respond within 24 hours inland and up to 2 weeks overseas.
