SPECIFICATIONS
Can Be Customized:
| Parameter | Specification |
|---|---|
| Conductor Type | Stranded (IEC 60228 Class 2/5/6) |
| Conductor Ø | 0.6-4.0mm |
| Max. Speed | 1000 RPM |
| Untwisting Rate | 0-100% Stepless Adj. |
| Spool Size | Ø200/250/300mm Fiber Spools |
| Rotation Direction | S/Z Selectable |
| Braking Response | 3-10 Seconds (Wire Break) |
APPLICATION&FEATURES
Application:
Designed for untwisting cores in various data cables, communication cables, control cables,
and other specialty cables.
Features:
utilizes a robust rotary frame structure welded from high-strength steel plates.
Low rotational inertia of the revolving body enables high rotational speeds.
Operates with smooth motion and low noise.
Untwisting speed is synchronized with the host machine via an encoder.
OUR SERVICE
Provide Free Pre-sales Training:
We can provide customer training to ensure that the customer can operate the machine fully—this includes correct operating mode, your maintenance method correctly and removing simple problems.
Customer On-site Installation Guide:
The buyer pays for the round-trip airfare, board, lodging, security, and each person's daily wage.
After-sales Service Content Details:
We support the After-sales in response quickly, to complete the delivery.
Free service guarantee period: 12 months from the date of shipment (except for wearing parts).
We will charge you for travel fees and other costs.
If the visa is received on time, our engineers will respond within 24 hours inland and up to 2 weeks overseas.
