SPARK TEST FONKSİYONU İLE 630 TEL YÜKSELTME MAKİNESİ

İki yönlü makara geri sarma: Büyük↔Küçük makara transferi
Yalıtım hatası tespiti için entegre 0-15kV kıvılcım test cihazı
Test arızası üzerine otomatik durdurma ve arıza noktasına geri sarma
PLC kontrollü sabit gerilim (600m / dak maksimum hız) IEC60243 güvenlik standartlarına uygundur
TALEP GÖNDER
Ürün Detayları

ÖZELLİKLER



Özelleştirilebilir:

Parametre AdıDeğer
Fonksiyonİki Yönlü Sarma (Büyük ↔ Küçük Bobinler)
İşık Testi Gerilimi0-15 kV Ayarlanabilir
Maksimum Hat Hızı600 m/dakika
Bobin Kapasitesi∅ 800-1500 mm (Büyük) / ∅ 400-630 mm (Küçük)
Güç Kaynağı380V/50Hz (3 Fazlı)
Kontrol SistemiPLC + Dokunmatik Ekran HMI
Otomatik Durma Tepkisi≤0,1 saniye
Sarma Hassasiyeti±0,2% Gerilim Kontrolü
Çerçeve MalzemesiToz Boyalı Çelik


UYGULAMA VE ÖZELLİKLER

Tel sarma makinesi, teli daha büyük bir bobinden (örneğin 630 mm) daha küçük bir bobine (örneğin 400 mm) sarmak için tasarlanmıştır.


Arada bir ışık çarpması test cihazı bulunur; eğer ışık çarpması testi başarısız olursa, makine yavaşça durur, ardından ters yöne hareket eder ve tel ışık çarpması sorunu yaşayan bölüme geri döner.

Uygulamalar:

  • Ambalajlama, kalite kontrolü veya akış ardışık işleme için bobinler arasında kablo/tel sarma

  • Tel/kablo üretim hatlarında zorunlu izolasyon kusuru tespiti

  • Bakır/alüminyum tellerin geri dönüşümü ve yeniden işlenmesi

Özellikler:

  • Çift Modlu Sarma: Bobin boyutlarını esnekçe değiştirme (büyük↔küçük)

  • Gerçek Zamanlı İşık Çarpması Testi: Ayarlanabilir voltajlarda anlık hata tespiti

  • Otomatik Hata Konumu Belirleme: Duraklatma + ters çevirme ile izolasyon delikleri tespiti

  • Gerilim Kontrolü: Yüksek hızlı çalışma sırasında tel deformasyonunu önleme

  • Veri Kaydı: Kalite güvencesi uyumluluğu için test sonuçlarını kaydetme (IEC 60243 standardı)




İşık Çarpması Test Fonksiyonuna Sahip 630 Tel Sarma Makinesinin Üç Detaylı Görüntüsü: Sol: Mavi metal çerçeve, tel sarma mekanizmaları, farklı renklerde bileşenler (sarı/turuncu) ve arka plandaki tel bobinleri gösteren makinenin tam görünümü. Bu, tel sarma ve ışık çarpması testi operasyonları için entegre yapılandırmayı illüstre eder. Orta: İnveterler, terminal blokları ve kablolama düzenlemelerini gösteren elektrik kontrol kasasının iç görünümü. Hassas sarma ve ışık çarpması testi işlevlerini destekleyen otomasyonlu kontrol sistemini vurgular. Sağ: Turuncu renkli ışık çarpması test modülü, operatör paneli ve simetrik tel işleme yapısını vurgulayan yan görünüm. Bu, makinenin hem tel sarma hem de kalite denetimi sağlayan çift amaçlı tasarımını gösterir.




HİZMETLERİMİZ


Ücretsiz Satış Öncesi Eğitim Sağlama:

Müşterilerin makineyi tam olarak kullanabilmelerini sağlamak için müşteri eğitimi sağlayabiliriz — bu, doğru çalışma modu, doğru bakım yöntemi ve basit sorunların giderilmesini içerir.


Müşteri Sahada Kurulum Rehberliği:

Alıcı, gidiş-dönüş uçak bileti, konaklama, güvenlik ve her birinin günlük ücretini öder.


Satış Sonrası Hizmet İçeriği Detayları:

Satış sonrası hizmetlerde hızlı yanıt vermeyi destekleriz ve teslimatı tamamlamak için çalışırız.

Ücretsiz hizmet garantisi süresi: Kargo tarihinden itibaren 12 ay (aşınma parçaları hariç).

Seyahat ücretleri ve diğer giderler için size ücretlendireceğiz.

Vize zamanında alınırsa, mühendislerimiz iç hatta 24 saat içinde, yurtdışında ise en fazla 2 hafta içinde yanıt verir.
