SPECIFICATION
Can Be Customized:
| Parameter | Specification |
|---|---|
| Application | HS Wire Extrusion Lines |
| Motor Power | 0.37 KW |
| Max Line Speed | 1000 m/min (Noise ↑>400 m/min) |
| Stability Control | Anti-Whip Flyer Design |
| Tension System | Adjustable Magnetic Braking |
| Bobbin Size | Φ630 mm |
| Barrel Material | Stainless Steel (316L) |
| Bobbin Load Capacity | 500 kg |
| Loading Mechanism | Electric Hydraulic / Lead Screw Lifting |
| Total Weight | 500 kg |
APPLICATION&FEATURES
APPLICATION:
HS Wire Extrusion Lines
Cable/Wire Continuous Production：Essential cable reel payoff solution for continuous production.
Precision Tension Processes
Large-Diameter Wire Unwinding (≤Φ630mm)
High-Speed Extrusion (≤1000m/min)
FEATURES:
Full 316L Stainless Steel Construction for the robust pay-off stand.
500kg Heavy-Bobbin Handling
0.37KW Drive + Magnetic Tension! (Near-zero slip)
E-Hydraulic/Lead Screw Lift System
Anti-Whip Stability (500m/min+)
OUR SERVICE
Provide Free Pre-sales Training:
We can provide customer training to ensure that the customer can operate the machine fully—this includes correct operating mode, your maintenance method correctly and removing simple problems.
Customer On-site Installation Guide:
The buyer pays for the round-trip airfare, board, lodging, security, and each person's daily wage.
After-sales Service Content Details:
We support the After-sales in response quickly, to complete the delivery.
Free service guarantee period: 12 months from the date of shipment (except for wearing parts).
We will charge you for travel fees and other costs.
If the visa is received on time, our engineers will respond within 24 hours inland and up to 2 weeks overseas.
