SPECIFICATIONS
Can Be Customized:
| Parameter Name | Value/Description |
|---|---|
| Motor | 1.5kW Domestic Motor (Included) |
| Wire Guide Wheels | 4×Φ120 mm |
| Wire Passage Holes | ≥20 Holes |
| Center Height | 760mm (±20mm Adjustable) |
| Distribution System | 1+6+12+18 Stranding Plate + Eyelet Mold Base |
| Max Rotation Speed | 850 RPM |
| Electrical Control | Excluded (Motor Only) |
APPLICATION & FEATURES
Applications:
The Pre-twist Machine is essential for key processes such as:
Pre-twisting for Stranded Cables: Ensures superior compactness in power cables (e.g., ACSR) and data cables.
Spring Back Prevention: Effectively eliminates wire rebound in high-tensile conductors.
Multi-wire Processing: Capable of handling complex configurations like 1+6+12+18 structures.
Features:
Designed for high performance, the pre-twister offers:
High-Speed Operation: A maximum speed of 850 RPM for significantly boosted production efficiency.
Precision Adjustment: ±20mm vertical center height adaptation to fit diverse production line setups.
Modular Design: An integrated stranding plate and eyelet mold base for seamless wire distribution.
Robust Mechanics: Φ120mm guide wheels that minimize friction and protect wires from damage.
OUR SERVICE
Provide Free Pre-sales Training:
We can provide customer training to ensure that the customer can operate the machine fully—this includes correct operating mode, your maintenance method correctly and removing simple problems.
Customer On-site Installation Guide:
The buyer pays for the round-trip airfare, board, lodging, security, and each person's daily wage.
After-sales Service Content Details:
We support the After-sales in response quickly, to complete the delivery.
Free service guarantee period: 12 months from the date of shipment (except for wearing parts).
We will charge you for travel fees and other costs.
If the visa is received on time, our engineers will respond within 24 hours inland and up to 2 weeks overseas.
